- PRECISELY MACHINED BASE
- HIGH TEMPERATURE RUBBER LINING ON THE ROLLER FOR PERFECT GRIP
- AC MOTOR WITH VFD GIVES STEP LESS VARIATION OF SPEED OVER THE ENTIRE RANGE.
Other Products
SELF ALIGNED TYPE TANK ROTATOR - ZT-20 TON
THESE ROTATORS ARE DESIGNED AND MANUFACTURED TO SUIT NEED OF ROTATING SHELLS FOR CIRCULAR SEAM WELDING.PRECISELY FABRICATED AND MACHINED STRUCTURE ALONG WITH PERFECTLY ALIGNED SYSTEM ENSURES SMOOTH ROTATION OF THE SHELLS.THERE IS NO NEED TO ADJUST THE DISTANCE BETWEEN THE TURNING ROLLS AS THE Y ADJUST AS PER THE DIAMETER OF THE SHELL.
| ZT-20 | 20 TON |
| WHEEL DIA (MM) | 300 |
| WORK PIECE DIA (MM) | 500-3800 |
| WHEEL WIDTH (MM) | 120 |
| NO OF WHEEL | 8 NO |
| WHEEL SPEED | 0.8-0.16 MTRS / MIN |
| WHEEL MATERIAL | RUBBER+CISTEEL/POLYURETHANE+CI STEEL |
| INPUT SUPPLY | 3 PHASE 440 V AC |
